JT-NV400NC Vertical Chamfering Machine

NC Vertical Chamfering Machine


Voltage 220V/3PH
Spindle motor 1HP(2000~12000rpm)-ER25
Work stroke X:400mm Y:400mm Z:150mm
Bevel speed 100~5000mm/Min free run speed:10M/min
Numerical control system 5.6”color screen+ triaxial controller
Machine size L:1000mm W:1100mm H:2000mm
Cover an area L:2000mm W:1100mm H:2000mm
Include external control box
  • Controller:
    ◆ easy to setup original and destination.
    ◆ easy to setup speed and feed rate.
  • Plunger:
    ◆ adopt pneumatic crlinder locked workpeice.
    ◆ will be withdraw and release when finish.
    ◆ adopt servo motor control axial feed.
  • Safety features:
    ◆ stop action for lack of air pressure.
    ◆ overload protection, can’t start when workpiece
        have not chip hold down
  • Cutter:
    ◆ adopt with side mill cutting, the surface of workpeice will be More smoothly after chamfered
    ◆ adjustment cutting point to make the full using of side knife.
