JT-NC1200SNC Chamfering Machine-Rack Dedicated Type

NC Chamfering Machine-Template Dedicated Type


Voltage 220V/3PH
Spindle motor 1HP(2000~12000rpm)Variable
Bevel angle 45 deg
Height of bevel 0~3C
Speed of bevel 100~5000m/min
Round trip speed:10M/min
Work piece size L:150~1200mm W:15~60mm H:15~60mm
Numerical control system 5”screen
Machine size L2000*W630*H850mm
Cover an area L2400mm W950mm H1800mm
  • Controller:
    ◆ easy to setup original and destination.
    ◆ easy to setup speed and feed rate.
  • Plunger:
    ◆ adopt pneumatic crlinder locked workpeice.
    ◆ will be withdraw and release when finish.
    ◆ adopt servo motor control axial feed.
  • Safety features:
    ◆ stop action for lack of air pressure.
    ◆ overload protection, can’t start when workpiece
        have not chip hold down
  • Cutter:
    ◆ adopt with side mill cutting, the surface of workpeice will be More smoothly after chamfered
    ◆ adjustment cutting point to make the full using of side knife.
