JT-NC800NC Chamfering Machine-Template Dedicated Type
Enlarge
| MODEL | JT-NC800 |
|---|---|
| Voltage | 220V/3PH |
| Spindle motor | 1HP(2000～12000rpm)Variable |
| Bevel angle | 45 deg |
| Height of bevel | 0~10C (Fractional) |
| Speed of bevel | 0～10M/min Round trip speed:15M/min |
| Work piece size | L:800mm W:30~800mm H:0~100mm |
| Numerical control system | 10”color touch screen＋NC control |
| Work table size | L1500*W780*H100mm HRC50° |
| Machine size | L:2000mm W:1300mm H:1540mm |
- Adopt servo motor and NC controller, quick and accurate for chamfering.
- Adopt touch screen, easy to setup stroke, bevel speed, feed rate, fine dressing.
- Bevel model:
◆ Unilateral bevel: fraction and find dressing
◆ Bilateral bevel: round trip bevel and find dressing
◆ Vertical bevel: hydraulic axial - Safety features ( Forced start or stop)
◆ when hydraulic pressure insufficient
◆ when workpiece have not chip hold down
