JT-100RPortable Regular Chamfering Machine
Enlarge
| MODEL | JT-100R |
|---|---|
| Capacity | 0~3C |
| Table Size | Ø100 × 30 × 6 mm |
| Motor | AC100V-240V 50/60HZ 1PH |
| Speed | 11000 r.p.m |
| Variable Speed | 2800~11000 r.p.m |
| Non Load Motor | 670W 6.0A |
| Blade Size | SPMW 0903 ADTR |
| NW/GW | 2.4/2.7kgs |
| Box Size | 38×13×14cm |
| Min diameter for inside bevels | Ø20mm (Another mini holder available for chamfering workpeice with inner diameter 9mm.) |
| BLADE | SPMW0903ADTR |
- Optional 2R.3R blade for C+R dual angle.
CUTTER+2PCS BLADE
2R 3R TYPE BLADE
2R 3R TYPE BLADE
2R 3R TYPE BLADE
