JT-NH1000Both End With Linear Guide Chamfering Machine
Enlarge
| MODEL | JT-NH1000 |
|---|---|
| Voltage | 220V/3PH |
| Spindle motor | 1HP(2000～12000rpm)Variable |
| Servo track | X stroke:100mm Y stroke:100mm |
| Z-axis manual flat track | Stroke:100mm |
| Numerical control system | 5.6”color screen+ hand wheel |
| Work table size | L1000*W500*H50mm |
| Machine size | 1000*900*800mm |
- Available for every brand line guide chamfering
- Chamfering mode
◆ Locked one at a time by fixture jig
◆ chamfering one unilateral face at a time
◆ X.Y axis: automatic advance
Z axis: manual set - Cutter
45deg disposable carbide end mill
