JT-NYH950Both Ends With Linear Guide Chamfering Machine
Enlarge
| MODEL | JT-NYH950 |
|---|---|
| Voltage | 220V/3PH |
| Spindle motor | 1HP(2000～12000rpm)Variable |
| Servo track | X stroke:100mm Y stroke:100mm |
| Z-axis manual flat track | Stroke:100mm |
| Numerical control system | 10.4”color screen+ hand wheel+ Milling machine second operation panel |
| Work table size | L950*W500*H57mm |
| Machine size | 1060*1000*1375mm |
- Available for every brand line guide chamfering.
- Chamfering mode:
◆ Locked one at a time by fixture jig
◆ chamfering one unilateral face at a time
◆ X.Y axis: automatic advance
Z axis: manual set - Cutter:
45deg disposable carbide end mill
